มา Integrate SIP softphone ใช้งานร่วมกับ Mumble Server และ Talkkonnect

ทำการสร้างไฟล์ nano  /mumsi/config/config.ini ดังนี้ครับ

[general]

# valid values for log level are: ERROR, WARN, NOTICE, INFO, DEBUG

logLevel = NOTICE

[sip]

# list of valid SIP URIs for incoming connections separated by space

# supported wildcards: *

# if you want to allow calls from any URI, write *@*

validUriExpression = *@sip.example.com *@127.0.0.1

host = sip.linphone.org

port = 5060

user = <username>

password = <password>

# length of single voice frame in ms. Valid values are 10, 20, 40, 60 ms.

# Adjust it if you need to meet the specific bandwidth requirements of Murmur server

frameLength = 40

# Set the maximum number of SIP calls to allow simultaneously. This should be <= 32.

# If you need more, recompile PJSUA LIB and also modify the define in main.hpp.

max_calls = 1

[mumble]

#mumble.ipptt.co

host = mumble-demo.haocomm.com

port = 50000

user = <username>

password = <password>

channelNameExpression = <channel>

# When here is no SIP connection, the mumble state is set to self_mute/self_deaf

# so the other users can easily see whether the SIP is connected even when not

# in the same group

autodeaf = 1

# Bitrate of Opus encoder in B/s

# Adjust it if you need to meet the specific bandwidth requirements of Murmur server

opusEncoderBitrate = 16000

# Set to 1 to use client certificates. The certs must be named <user>-cert.pem and

# the private keys <user>-key.pem.

use_certs = 0

[app]

# Caller PIN needed to authenticate the phone call itself. The caller presses

# the PIN, followed by the hash ‘#’ key. On success, the caller is

# unmuted/undeafened. On failure, the SIP call is hung up.

channel = HAM-CB

pin = 9999

[files]

# These files are used for the caller and mumble channel audio clips.

# The paths below assume that you are running ./mumsi in the build/ dir.

#welcome = ../media/welcome.wav

#prompt_pin = ../media/prompt-pin.wav

#entering_channel = ../media/entering-channel.wav

#announce_new_caller = ../media/announce-new-caller.wav

#invalid_pin = ../media/invalid-pin.wav

#goodbye = ../media/goodbye.wav

#mute_on = ../media/mute-on.wav

#mute_off = ../media/mute-off.wav

#menu = ../media/menu.wav

welcome = /app/media/welcome.wav

prompt_pin = /app/media/prompt-pin.wav

entering_channel = /app/media/entering-channel.wav

announce_new_caller = /app/media/announce-new-caller.wav

invalid_pin = /app/media/invalid-pin.wav

goodbye = /app/media/goodbye.wav

mute_on = /app/media/mute-on.wav

mute_off = /app/media/mute-off.wav

menu = /app/media/menu.wav
